Dunnewolt

Quest' è una macchina di seconda mano da Texfinity. Possiamo offrirlo completamente revisionato o in condizione attuale. Per ogni macchina trovera informazioni specifiche:

Extention for existing Bag Loading System:

• 2 buffer lanes:
  • rails, curves, switches and stop positions with pushers
  • capacity +/- 1.320 kg, based on 22 bags of 60kg each
• 1 Automatic drop-unit for CBW
  • Lacated above loading position CBW
  • Automatic loading with stabilising unit
  • Automatic bag closing system

Included parts:

• 1 open/close unit
• 24 straight rail incl. connections
• 6 switches 90°
• 2 stop positions with pushers
• 2 full-lane detectors
• Re-use existing curve 90°
• 1 set suspension materials
• 1 compressed air circuit
  • water seperator with reducing valve on the connection points with local toggle
  • Compressed air tubes, connections, etc.
• 1 Control circuit 24V DC from the sensors and valvues to the distribution boxes, inclusive secondary cables to the control unit.
• 22 Bag containers type 820:
  • Double trolley loop, 8 steal rollers with 4 shafts
  • Capacity 60kg of normal laundry linen per container
  • Bags are 100% polyester, and can be removed with 2 zippers
  • Adapted for automatic closing and opening
  • Exact length of bags to be defined.

---

Documentazione

D2_loop_10_bags_and_1_extra_rail_10_bags...
D2_loop_10_bags_and_3_extra_rails_10_bag...
D2_sorting_6_bags_and_6_rails_10_bags_.E...
D2_loop_20_bags_.EN..pdf
D2_loop_10_bags_and_2_extra_rails_10_bag...
D2_sorting_4_bags_and_4_rails_10_bags_.E...
D2_sorting_5_bags_and_5_rails_10_bags_.E...
D2_loop_10_bags_.EN..pdf

---
